Lightwin 3m LC-ST Duplex Multimode OM3 Fiber Optic Patch Cable, 50/125µm, PVC Jacket, Black LDP-50 LC-ST 3.0 OM3

2000 MHz·km bandwidth at 850 nm – this Lightwin OM3 multimode fiber optic patch cable delivers 10 Gigabit Ethernet over distances up to 300 meters, making it a future-proof choice for your high-speed network. Whether you're setting up a home lab or upgrading your office backbone, this 3-meter duplex cable with LC and ST connectors ensures reliable, low-loss connections.

Advantages

OM3 fiber supports 10GbE up to 300 m, so you're ready for tomorrow's bandwidth needs today. The duplex zip-cord design with a durable PVC jacket resists wear and simplifies cable management. Crossed polarity (A-B) means you can plug it in without worrying about swapping connectors – ideal for standard network setups. Plus, it's RoHS compliant, so you're making an environmentally responsible choice.

Suitable for

• Data center interconnects and server-to-switch links
• Enterprise backbone cabling for high-speed LANs
• Fibre Channel storage area networks
• Telecommunications rooms and horizontal cabling

Key specifications

• Connector A: LC Male
• Connector B: ST Male
• Cable length: 3 m
• Fiber type: Multimode OM3, 50/125 µm
• Number of fibers: 2 (Duplex)
• Jacket material: PVC, black
• Insertion loss: < 0.3 dB typical
• Return loss: > 30 dB typical
• Bandwidth: 2000 MHz·km at 850 nm
• Operating temperature: -20°C to 70°C

Recommendations

For optimal performance, pair with OM3-compatible transceivers and ensure proper bend radius during installation. Test with a fiber optic power meter to verify link quality.
