Finder Installation Contactor 22.64.0.230.4610 (226402304610)

25 A rated current (AC-1) and 4 normally open contacts – this Finder 22 Series installation contactor handles demanding loads while operating silently. No annoying hum, just reliable switching for your lighting or heating circuits.

Why choose this contactor?

Traditional contactors can be noisy, especially in quiet environments like offices, hotels, or homes. The Finder 22.64.0.230.4610 eliminates that hum thanks to its silent design. It's perfect for switching multiple circuits simultaneously with its 4 NO contacts, and the 230 V AC coil means you can control it directly from standard mains voltage – no extra transformer needed.

Who is it for?

Electricians and panel builders who need a dependable DIN-rail mounted contactor for lighting, heating, or other AC loads up to 25 A. Its compact size saves space in distribution boards, and the screw terminals make wiring quick and secure.

Key specifications

• Number of poles: 4
• Contact configuration: 4 NO (normally open)
• Rated current (AC-1): 25 A
• Rated voltage (AC-1): 400 V AC
• Coil voltage: 230 V AC
• Mounting: DIN rail (EN 60715)
• Electrical durability (AC-1): 100,000 cycles
• Mechanical durability: 1,000,000 cycles
• Operating temperature: -40 to +40 °C
• Protection degree: IP20
• Terminal type: Screw terminals
• Max terminal capacity: 6 mm² (single wire)
• Contact material: AgNi
• Max switching power (AC-1): 10 kVA

How to use

Mount the contactor on a standard DIN rail in your distribution board. Connect the coil to your 230 V AC control circuit, and wire the loads to the 4 NO contacts. Always follow local wiring regulations and ensure the coil voltage matches your control voltage.

Tips: If you're switching high inrush loads frequently, consider derating the contactor or choosing a larger model. For optimal performance, keep the terminals clean and tighten screws to the recommended torque.
