ACT RL2401 10m 4x LC į 4x LC LSZH OM3 akvamarino optinis komutacinis kabelis

This cable is made for network engineers and data centre technicians who need to connect multiple fibre ports without creating a tangled mess. The ACT RL2401 is a 10-metre multimode patch cable that combines four LC duplex channels into one slim, aqua-coloured jacket. Instead of running four separate cables, you get a single, organised link that saves space and simplifies maintenance in high-density racks.

Why it stands out

• Four LC connectors on each end let you link four ports at once – perfect for high-port-count switches and patch panels.
• OM3 multimode fibre with 50/125 µm core supports 10GbE up to 300 m and 40/100GbE up to 100 m, so it's ready for today's fast networks.
• The LSZH (Low Smoke Zero Halogen) jacket is safer in enclosed spaces – it emits minimal smoke and no toxic halogens if there's a fire.
• Aqua colour instantly identifies it as OM3 multimode, making troubleshooting and maintenance quicker.
• Typical insertion loss below 0.3 dB per connector ensures a strong, reliable signal.
• RoHS and CE compliant, so you know it meets professional standards.

Who it's for

If you manage a data centre, SAN, or any high-density LAN environment, this cable is a smart choice. It's also great for FTTx deployments where space and reliability matter. The four LC connections are colour-coded and keyed for correct polarity, so even in crowded racks, installation is straightforward.

Key specifications

• Brand: ACT
• Model: RL2401
• MPN: RL2401
• EAN: 8716065351552
• Cable length: 10 m
• Fibre type: Multimode OM3
• Core/cladding diameter: 50/125 µm
• Connector A: 4x LC
• Connector B: 4x LC
• Number of fibres: 4
• Jacket material: LSZH (Low Smoke Zero Halogen)
• Cable colour: Aqua
• Insertion loss (typical): < 0.3 dB per connector
• Return loss (typical): > 30 dB
• Bandwidth (850 nm): 1500 MHz·km OFL, 2000 MHz·km EMB
• Supported protocols: 10GbE, 40GbE, 100GbE
• Maximum distance (10GbE): 300 m
• Maximum distance (40/100GbE): 100 m (SR4/SR10)
• Operating temperature: -20°C to 70°C
• Compliance: RoHS, CE
• Application: Data centre, SAN, LAN, FTTx

How to use it

Simply plug the four LC connectors into your switches, servers, or patch panels. The keyed connectors ensure correct polarity, and the slim jacket keeps your cable management neat. Because it's LSZH, you can use it in public buildings and enclosed spaces with confidence.

Final note

When you need four reliable OM3 links in one tidy cable, the ACT RL2401 keeps your infrastructure organised and ready for high-speed networking.
